Architecture

openhome is a local-first monorepo. Every component runs on the home box; the cloud

is optional and opt-in.

                          ┌─────────────────────────────┐
                          │        apps/app             │
                          │   web + mobile control UI   │
                          └──────────────┬──────────────┘
                                         │ HTTPS / WebSocket
                          ┌──────────────▼──────────────┐
                          │        services/hub         │
                          │  ┌───────────────────────┐  │
                          │  │      Agent loop       │  │  ← local LLM (Ollama)
                          │  │  monitor · automate · │  │     or cloud (opt-in)
                          │  │  answer · notify      │  │
                          │  └───────────────────────┘  │
                          │  REST API · rules engine ·  │
                          │  event bus · auth           │
                          └───┬──────────────┬──────────┘
                              │ MQTT         │ SQL / files
              ┌───────────────▼──┐   ┌───────▼──────────────┐
              │ device-gateway   │   │      storage         │
              │ Matter · Zigbee  │   │ recordings · backups │
              │ Z-Wave · ONVIF   │   │ metadata DB (SQLite/ │
              │ RTSP · MQTT      │   │ Postgres)            │
              └───┬────┬────┬────┘   └──────────────────────┘
                  │    │    │
              cameras locks lights ...   (integrations/)

Principles

1. Local-first. The LAN is the source of truth. Internet outage ≠ home outage.
2. Event-driven. Devices publish events to an MQTT bus; the hub subscribes and reacts.
3. Protocol-agnostic core. The hub speaks a normalized device schema

(packages/shared); adapters translate vendor protocols into it.

1. Agent as operator, not gatekeeper. The agent automates and informs. Safety-

critical actions (unlock door, disable alarm) require explicit policy + confirmation.

1. Privacy by construction. Video/audio never leaves the box unless a user

explicitly enables a cloud feature for a specific stream.

Components

services/hub — the brain

• API: Fastify REST + WebSocket for the app and integrations.
• Event bus: subscribes to MQTT, normalizes events, fans out to rules + agent.
• Rules engine: declarative automations ("if door unlocked after 11pm and no one home → notify").
• Agent loop: an LLM-driven operator. Tools = device controls, footage search,

notifications. Model is pluggable: local (Ollama) by default, cloud opt-in.

• Auth: local accounts, per-device/room scopes, and an approval policy for

sensitive actions.

services/device-gateway — the hands

Adapter processes that bridge physical protocols to the MQTT bus using the shared

device schema. Planned adapters:

• Matter / Thread (via matter.js) — the strategic default going forward.
• Zigbee (via zigbee2mqtt) and Z-Wave (via Z-Wave JS).
• Cameras: ONVIF discovery + RTSP ingest; snapshots and event clips to storage.
• Generic MQTT for DIY / ESPHome devices.

services/storage — the NAS layer

• Recording storage with retention policies and ring-buffer eviction.
• Metadata DB (SQLite for single-box, Postgres for bigger installs).
• Backup/export so users can move their data off the box any time.

apps/app — the face

• Web dashboard first (Vite + React), then React Native mobile.
• Live camera views, device control, automation editor, agent chat.
• Talks only to the hub — never directly to the cloud.

packages/shared — the contract

• Normalized Device, DeviceEvent, Capability types.
• Zod schemas so hub, gateway, and app validate the same shapes.

Data flows

Event: device → gateway adapter → MQTT → hub bus → (rules + agent + app push).

Command: app/agent → hub API → MQTT command topic → gateway adapter → device.

Agent query ("who was at the door at 2pm?"): agent → storage (clip search) +

device metadata → LLM → answer, with the source clip linked in the app.

Cloud, when you want it

Cloud is a per-feature toggle, never a requirement:

• Swap the agent's model provider to a cloud LLM for heavier reasoning.
• Optional encrypted off-site backup of the metadata DB (not raw video by default).
• Optional remote access via the user's own relay/VPN (e.g. Tailscale) — no open-home

cloud in the middle.
